IBM-40 |
IBM-65 |
IBM-85 |
IBM-135 |
| Screw Diameter(mm) |
Φ45 |
Φ50 |
Φ50 |
Φ50 |
Φ70 |
| Max. Shot volume(HDPE.g) |
180 |
240 |
310 |
280 |
560 |
| Preform mold clamping force(tons) |
35 |
50 |
70 |
125 |
| Blow mold clamping force(kn) |
7 |
14 |
14 |
24 |
| Max. Swing radius(mm) |
500 |
650 |
650 |
880 |
| Trigger bar length(mm) |
305 |
550 |
550 |
915 |
| Max.Die set size(mm) |
W450xL390 |
W620xL430 |
W620xL430 |
W900xL480 |
| Mold height(mm) |
228.6 |
228.6 |
254 |
254 |
| Mold opening stroke(mm) |
120 |
135 |
135 |
160 |
| Oil pump driving motor(kw) |
27 |
34 |
41 |
41 |
60 |
| Total connected load(kw) |
35 |
43 |
52 |
53 |
74 |
| Average power consumption(kw) |
24 |
30 |
35 |
37 |
52 |
| Compressed air at 10bar(㎥/h) |
20 |
34 |
38 |
55 |
| Mold cooling water : 10℃-5bar(1/min) |
1.9 |
2.6 |
2.8 |
3.8 |
| Oil cooling water : 15℃-5bar(1/min) |
3.2 |
4.2 |
4.4 |
5.7 |
| Total cooling requriment(kj/h) |
170000 |
240000 |
260000 |
320000 |
Machine size |
Width(mm) |
1520 |
1805 |
1805 |
2250 |
| Length(mm) |
4050 |
4850 |
4850 |
5700 |
| Height(mm) |
35 |
2550 |
2550 |
35 |
| Machine Weight |
6.4 |
9.5 |
12 |
16 |
